STEELPUMPS JETBOX 80 100 120 RESIDENTIAL PRESSURIZATION SYSTEM

€ 1.185,60

Excl. VAT

Varianten

Steelpumps	JETBOX 80 Residential pressurization system with 200 with inverter	€ 1.185,60 Stock Order

Steelpumps	JETBOX 100 Residential pressurization system with 200 with inverter	€ 1.224,08 Stock Order

Steelpumps	JETBOX 120 INTELLY Residential pressurization system with 200 with inverter	€ 2.028,00 Stock Order

Omschrijving

salesteam@ziggo.nl
STEELPUMPS JETBOX 80 100 120 RESIDENTIAL PRESSURIZATION SYSTEM
0224-850552
0031 224 850552 (international)
06-52634163
0031 652634163 (international)

Residential pressurization system from 300 to 500 liters
Complete and compact ready-to-use residential pressurization system. It can be connected directly to the municipal water
network because it consists of a 300 / 500-liter storage tank inside which is installed a pump equipped with an electronic
pressure switch, a 1-liter stainless steel expansion tank, and a Quick Stop loading fl oat switch. All fully assembled and
ready for installation. TANKPRESS ECO is essential both to supply pressurized water even in situations of water shortage
from the aqueduct and to prevent pollution of drinking water distribution networks from contamination from connected
utilities as required by EN 1717.

General features
• Domestic boosting
• Plug and Play, fully assembled system ready for installation
• 300 liter and 500-liter tank range
• Pump with integrated control of 60 l/min with dry running protection,
automatic water shortage reset
• Antiblocking System for 72-hour inactivity
• 2-liter stainless steel expansion tank
• Quick Stop tank loading float
• 3/4” inlet and 1” outlet

Materials
• Motor body: techopolymer
• Shaft in Aisi 420
• Diffuser, venturi and impeller in noryl
• Rear cover in technical polypropylene
• Support foot in Aisi 304 and rubber vibration dampers
• Mechanical seal in ceramic/graphite + double gasket
• Oil chamber on the seal
• A2 stainless steel hardware
• NBR70 O-ring
• Electric cable H07RN8-F - 9 m
• Tropicalized electronic board according to Rohs standards
• Class F insulated motor
• Monolithic PE outdoor tank

STANDARDS AND CERTIFICATIONS
Suitability for food contact:
IIP Test Report No. 821LP/2021
of 20/10/2021
Meets the requirements:
Regulation 1935/2004/EC
EU Regulation 2023/2006
EU Regulation 10/2011
EU Regulation 213/218
Presidential Decree (D.P.R.)
No. 777/82 and s.m.i.
(D. M. 21/03/73 and s.m.i.
D. M. no. 174 of 06/04/2004

Colours on request

LEAD TERM ABOUT 1-1,5 WEEK AFTER ORDER
